ED SD+ED SD+
Architectural Square Downlight
- Architectural luminaire with direct lighting distribution.
- Light source: COB LED.
- High-efficiency low-glare integral reflectors come in the following beam angles: Narrow 15º, Medium 35º, and Flood 55º.
- Adjustable trim assembly can be tilted up to 30º for wall wash applications.
- Available with an optional flat frame plate for NC installations.
- Suitable for recessed insulated ceilings or damp locations.
- LED spot is rated for 60,000 hrs. L70 with a +90 CRI.
- Has a proven record in office, commercial and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL standards.
Resources
Materials
- Metal
Shape
- Square
Color / Finish
- Black
- White
Lumens
- 1425 Lm
- 1455 Lm
- 1485 Lm
- 1900 Lm
- 1940 Lm
- 1980 Lm
- 2375 Lm
- 2425 Lm
- 2475 Lm
Watts
- 15 w
- 20 w
- 25 w
Adjustability
- Tilt Optics
Aperture
- 4 In.
Beam Angle
- 15
- 35
- 55
CCT
- 3000K
- 3500K
- 4000K
CRI
- 90 CRI
Circuit
- Single Circuit
Dimming Protocol
- 0-10 V
Dimming Range
- 1%
Distribution
- Direct
- Medium
- Medium Wide
- Narrow
Installation Type
- New Construction
- Retrofit & Remodel
Lamp Life
- 60000 hrs
Lamp Source
- LED
Listings
- cULus
Ratings & Compliance
- Dry
- Made in Canada
Trim Finish
- Black
- White
Trim Type
- Downlight
- Lensed
- Reflector
- Regressed
- Wall Wash
Voltage
- 120 V
- 277 V
- 347 V
Warranty
- 5 yr
