ED COR+

Illuminated Round Luminaire

  • Architectural luminaire with direct/indirect lighting distribution.
  • Light source: COB LED.
  • Extremely durable round diffusor is made from frosted PMMA polycarbonate for even lighting distribution.
  • Steel body with built-in-driver, available in white or black finish.
  • Suitable for surface and wall mounted installations.
  • LED spot is rated for 60,000hrs.
  • L70 with +90 CRI.
  • Has a proven record in office, commercial and retail installations.
  • Custom modifications are available.
  • ED luminaires are certified to CSA and UL Standards.
Specification Sheet

Resources

Specsheets


Photometry


BIM & CAD Files


Materials

  • Polycarbonate
  • Steel

Shape

  • Circular

Color / Finish

  • Black
  • Grey
  • White

Lumens

  • 1360 Lm
  • 1400 Lm
  • 1440 Lm
  • 1850 Lm
  • 1900 Lm
  • 1950 Lm
  • 2800 Lm
  • 2900 Lm
  • 3000 Lm

Watts

  • 15 w
  • 20 w
  • 30 w

CCT

  • 3000K
  • 3500K
  • 4000K

CRI

  • 90 CRI

Circuit

  • Single Circuit

Dimensions

  • H: 2.375 In. L: 11.5 In. W: 11.5 In.

Dimming Protocol

  • 0-10 V
  • DALI
  • ELV
  • Triac

Dimming Range

  • 1%
  • 10%
  • < 1%

Dynamic LED Color

  • BIOS Dynamic
  • RGBW
  • Tunable White

Lamp Life

  • 60000 hrs

Lamp Source

  • LED

Listings

  • cULus

Ratings & Compliance

  • Made in Canada

Static LED Color

  • BIOS Static

Voltage

  • 120 V
  • 277 V
  • 347 V

Warranty

  • 5 yr
