ED RD+ED RD+
Architectural Round Downlight
- Architectural luminaire with direct lighting distribution.
- Light source: COB LED High efficiency semi-specular integral reflector comes with 40º lighting distribution.
- Available with optional flat frame plate for NC installations.
- Suitable for recessed non insulated ceilings or damp locations.
- Choice of integrated reflector for standard downlight or asymmetric wallwash illumination.
- LED spot is rated for 60,000hrs. L70 with +85 CRI.
- Has a proven record in office, commercial and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL Standards
Resources
Shape
- Round
Color / Finish
- Black
- Grey
- White
Lumens
- 975 Lm
- 1000 Lm
- 1025 Lm
- 1950 Lm
- 2000 Lm
- 2050 Lm
Watts
- 10 w
- 20 w
Aperture
- 3 In.
Beam Angle
- 40
CCT
- 3000K
- 3500K
- 4000K
CRI
- 85 CRI
- 90 CRI
Circuit
- Single Circuit
Dimming Protocol
- 0-10 V
- DALI
- Triac
Dimming Range
- 1%
- 10%
Installation Type
- New Construction
- Retrofit & Remodel
Lamp Life
- 60000 hrs
Lamp Source
- LED
Listings
- CSA
- UL
Emergency Options
- Integral EM Battery
Ratings & Compliance
- Damp
- Made in Canada
Trim Finish
- Black
- Gray
- White
Trim Type
- Downlight
- Reflector
- Regressed
- Wall Wash
Voltage
- 120 V
- 277 V
- 347 V
Warranty
- 5 yr
