ED VERTEX+
ED Vertex+.jpg
ED Vertex+1.jpgED VERTEX+
Architectural Vertex Luminaire
- Architectural luminaire with direct or indirect distribution.
- Light source: LED board (5.5"/11"/22"/24").
- Diffused illumination is provided by high efficiency frosted opal lens.
- Suitable for surface,suspended and recessed installations.
- Extruded aluminum body comes with black or white finish.
- Also available with custom color options.
- LED Strips are rated for 60,000hrs. L80 with +90 CRI.
- Has a proven record in office, commercial and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL Standards.
Resources
Materials
- Aluminum
Mounting
- Recessed
- Surface
- Suspended
- Wall
Shape
- Linear
- Rectilinear
Color / Finish
- Black
- Custom
- White
Lumens
- 2610 Lm
- 2650 Lm
- 2690 Lm
- 5150 Lm
- 5250 Lm
- 5380 Lm
- 7720 Lm
- 7875 Lm
- 8030 Lm
Watts
- 25 w
- 50 w
- 75 w
CCT
- 3000K
- 3500K
- 4000K
CRI
- 85 CRI
- 90 CRI
Circuit
- Dual Circuit
- Single Circuit
Controls Options
- Daylight Sensor
- Occupancy Sensor
Dimensions
- H: 2.75 In. L: 33.40 In. W: 18.00 In.
- L: 48.97 In. W: 25.80 In.
- L: 64.54 In. W: 33.57 In.
Dimming Protocol
- 0-10 V
- 1-10 V
- Bluetooth Wireless
- DALI
- ELV
- Triac
Dimming Range
- 1%
- 10%
- < 1%
Distribution
- Direct
- Indirect
Dynamic LED Color
- BIOS Dynamic
- Tunable White
Lamp Life
- 60000 hrs
Lamp Source
- LED
Listings
- CSA
- ETL
- UL
Ratings & Compliance
- Damp
- Declare
- Made in Canada
Static LED Color
- BIOS Static
Up/Down Ratio
- 0/100 (Up/Down)
- 100/0 (Up/Down)
Voltage
- 120 V
- 277 V
- 347 V
Warranty
- 5 yr
