ED TRIANGLE+

Architectural Triangular Luminaire

 Architectural luminaire with direct or indirect distribution. Light source: LED board (5.5"/11"/22"/24"). Diffused illumination is provided by high efficiency frosted opal lens. Suitable for surface, suspended and recessed installations. Extruded aluminum body comes with white, black or grey finish. Also available with custom color options or vinyl decals. LED Strips are rated for 60,000hrs. L80 with +90 CRI. Has a proven record in office, commercial and retail installations. Custom modifications are available. ED luminaires are certified to CSA and UL Standards.
Specification Sheet

Resources

Materials

  • Aluminum

Mounting

  • Recessed
  • Surface
  • Suspended
  • Wall

Shape

  • Rectilinear
  • Triangular

Color / Finish

  • Black
  • Custom
  • Grey
  • White

Lumens

  • 2610 Lm
  • 2650 Lm
  • 2690 Lm
  • 5150 Lm
  • 5250 Lm
  • 5380 Lm
  • 7720 Lm
  • 7875 Lm
  • 8030 Lm

Watts

  • 25 w
  • 50 w
  • 75 w

CCT

  • 3000K
  • 3500K
  • 4000K

CRI

  • 85 CRI
  • 90 CRI

Controls Options

  • Daylight Sensor
  • Occupancy Sensor

Dimming Protocol

  • 0-10 V
  • 1-10 V
  • Bluetooth Wireless
  • DALI
  • ELV
  • Triac

Dimming Range

  • 1%
  • 10%
  • < 1%

Distribution

  • Direct
  • Direct/Indirect
  • Indirect

Dynamic LED Color

  • BIOS Dynamic
  • Tunable White

Listings

  • CSA
  • ETL
  • UL

Ratings & Compliance

  • Damp
  • Declare
  • Made in Canada

Static LED Color

  • BIOS Static

Up/Down Ratio

  • 0/100 (Up/Down)
  • 100/0 (Up/Down)
  • 30/70 (Up/Down)
  • 50/50 (Up/Down)

Warranty

  • 5 yr
