ED TUBE+ED TUBE+
Architectural Cylinder Luminaire
- Architectural luminaire with direct lighting distribution.
- Light source: COB LED.
- A high-efficiency integral louver combined with an opal lens insert provides excellent lighting distribution with a 40° beam.
- Circular internal louver is available in a wide range of finishes.
- Aluminum body of the luminaire comes with a built-in driver, available in a black or white finish.
- Suitable for surface-mounted and suspended installations.
- LED spot is rated for 60,000 hrs. L80 with +90 CRI.
- Has a proven record in office, commercial, and retail installations.
- Custom modifications are available.
- ED luminaires are certified to CSA and UL standards.
Resources
Materials
- Aluminum
Mounting
- Surface
- Suspended
Shape
- Cylinder
Color / Finish
- Black
- White
Lumens
- 1400
- 1430
- 1460
- 1910
- 1950
- 1990
- 2350
- 2400
- 2450
Watts
- 15
- 20
- 25
CCT
- 3000K
- 3500K
- 4000K
CRI
- 90
Circuit
- Single
Dimming Protocol
- 0-10 V
- DALI
Dimming Range
- 1%
- 10%
Distribution
- Direct
- Flood
- Wide
Lamp Life
- 60000
Lamp Source
- LED
Listings
- cULus
Ratings & Compliance
- Made in Canada
Voltage
- 120 V
- 277 V
Warranty
- 5
